Zigbee Router mode

General information:

USB stick in Zigbee router mode expands your existing Zigbee network:

amplifies the signal
increases the maximum number of devices in the network by 32

Important: you need to pair the stick to your Zigbee network for it to start working as Zigbee router

Configuring device as Zigbee router

Flashing router firmware

Go to https://smlight.tech/flasher/
Select your model
Press Update Firmware button
Select dongle serial port
Wait for connection
Enable pairing in your Zigbee network
Select firmware (Router)
Flash firmware
Immediately after the update, the device will start searching for the network, so it is important that the network is open at this moment.

Manuall pairing activation

If after flashing the device did not pair or you need to pair the device in another location, you can do this!

SLZB-07/MGx:

Go to https://smlight.tech/flasher/
Select your model
Press Router reconnect button
If that didn't work:
1. Download any serial terminal (e.g. terra term)
2. Connect the dongle to the PC
3. Open the dongle COM in the terminal at 115200 baurate
4. Send network leave

SLZB-07Px:

Go to https://smlight.tech/flasher/
Select your model
Press Router reconnect button
If that didn't work: repeat step "Flashing router firmware"

Troubleshooting

Сoordinator does not detect the dongle

Make sure your ZigBee network is open
Make sure the dongle is within range of your ZigBee network
Activate pairing on the dongle manually

The dongle appears offline after a while

This may not be true. Z2M marks ZigBee devices as offline if they do not report anything for a long time, but the router firmware has nothing to report (the device does not have any sensors) so the system may mark it as offline.

If the device is truly offline, all devices that were connected through it will become unavailable.

If the device offline then the most likely reason is that it is outside the coverage area of your Zigbee network.
