NEW SLZB-07p10 ZIGBEE USB RELEASED SPECIAL PRICE 14.98$
SLZB-07p10 CC2674P10 Zigbee + USB with 921 kbps serial speed! Limited quantity for this price available!
ATTENTION!
ZIGBEE FIRMWARE FOR ZIGBEE CHIP CC2674P10 IS STILL UNDER DEVELOPMENT.
YOU CAN BUY THIS DEVICE ONLY FOR DEVELOPMENT PURPOSES
CC2674P10 GPIOS for developers (corresponds to LAUNCHXL board CC2652P):
- RF: RF_24GHZ → DIO28, RF_HIGH_PA → DIO29;
- UART: TX → DIO13, RX → DIO12;
- LEDs: GREEN LED → DIO6, RED LED → DIO7;
- BOOT: BSL → DIO15, Reset → RESET_N;
WHAT MAKES SMLIGHT SLZB-07p10 THE BEST OPTION TO USE AS YOUR USB ZIGBEE ADAPTER?
KEY SPECIFICATIONS
FOR DEV PURPOSES
You will get your SLZB-07p10 ready for flash with unlocked bootloader. You will be able to flash your own firmware.
+20dB +3dB
Zigbee 3.0 SLZB-07p10 adapter has +20dB amplifier on board & +3dB antenna. Cover your farthest locations
TINY DESIGN
SLZB-07p10 has the smallest design among all Zigbee USB CC2674P10 based adapters with external antenna!
Zigbee/Thread/Matter ready
Chip supports Zigbee/Thread/Matter (requires firmware)
CHIPSETS AND TECHS
CC2674P10
Zigbee 3.0 SoC is based on the powerful chip CC2674P10 from Texas Instruments.
CP2102N
Best in class USB/UART SoC converter. Do not compromise on speed and quality
EFR32 Autoflash mode
SLZB-07p10 features autoflash mode for CC2674P10. If you want to flash over USB – just plug-and-do!
DIY PINOUTS
SLZB-07p10 is a DIY enthusiasts friendly: it contains pinouts for CC2674P10 chip
OTHERS
NEWBY? MANUAL!
Do not know how to start? No worries, exhaustive manual is included!
REMOTE ZIGBEE UPD
You can update chip remotely! You just need to have access to the server where the adapter is connected!
ROTATABLE ANTENNA
Rotatable in 3 dimensions powerfull antenna secures best positions for the best signal
MADE IN UKRAINE
SLZB-07p10 designed, developed and tested in Ukraine. Ukrainian quality guaranteed.
SMLIGHT SLZB-07p10 SPECIFICATIONS
SMLIGHT SLZB-07p10 FREQUENTY ASKED QUESTIONS (FAQ)
Product manual page: https://smlight.tech/manual-slzb-07/
Does SLZB-07p10 works with Home Assistant out of the box?
Yes, it does. Just plug in SLZB-07p10 into the USB port of your server and start ZHA Home Assistant or Zigbee2MQTT.
Can I set up multiple SLZB-07p10 coodinators with one Home Assistant?
Yes, you can run multiple SLZB-07p10 with your single server. Please note, that all of them should be connected to the same server. If you want to cover different rooms or even buildings, you can use SLZB-07p10 with your server and add SLZB-06 or SLZB-06M in other rooms or buildings. For running multiple coordinators, you just need to run a separate instance of Zigbee2MQTT or ZHA for each coordinator. More details can be found in this Article of the official manual.
Overall system architecture with multiple adapters looks like this:
Do I need to use extension cable?
Can I update firmware distantly, without physical access to the SLZB-07p10 ?
Yes, you can. Main chip used in SLZB-07p10 (CC2674P10) can be updated distantly from the other global point. That makes the device suitable for installation in rare-visited locations or installation places. You just need to have access to your server.
NEW SLZB-07p10 ZIGBEE USB RELEASED SPECIAL PRICE 9.98$
SLZB-07p10 CC2674P10 Zigbee + USB with 921 kbps serial speed! Limited quantity for this price available!
