NEW SLZB-07p7 ZIGBEE USB RELEASED SPECIAL PRICE 9.98$

SLZB-07p7 CC2652P7 Zigbee + USB with 921 kbps serial speed! Limited quantity for this price available!

SLZB-07 main page
SLZB-07 main page

WHAT MAKES SMLIGHT SLZB-07p7 THE BEST OPTION TO USE AS YOUR USB ZIGBEE ADAPTER?

SLZB-07p7
Other USB Zigbee Adapter 1
Other USB Zigbee Adapter 2
Based on fast CP2102 SoC?
Yes
No
No
External antenna for better coverage
Yes
Yes
No
Small and tiny design that does not interfere with other devices in server's USB port
Yes
No
No
Hardware flow control supported?
Yes
Yes
Yes
Four layers PCB to avoid RF interference with the USB and miniPC?
Yes
No
No
CC2652P7 integrated as chips on a single board to improve the system's stability rather as a combination of modules on the boards?
Yes
Yes
No
Supports CC2652P7 autoflash mode for flashing over USB?
Yes
Yes
Yes
Could be used with SLZB-06 Zigbee Ethernet adapter
Yes
No
No
SLZB-07 main page

KEY SPECIFICATIONS



PRE-FLASHED

Just plug-and-play. You will get your SLZB-07p7 pre-flashed and ready to use with your Home Assistant ZHA and Zigbee2MQTT

+20dB +3dB

Zigbee 3.0 SLZB-07p7 adapter has +20dB amplifier on board & +3dB antenna. Cover your farthest locations

TINY DESIGN

SLZB-07p7 has the smallest design among all Zigbee USB EFR32 based adapters with external antenna!

Zigbee 3.x support

Supports Zigbee 3.0 out of the box, pre-flashed and ready to use

CHIPSETS AND TECHS

CC2652P7

Zigbee 3.0 SoC is based on the powerful chip CC2652P7 from Texas Instruments, reliability confirmed by thousands of users.

CP2102N

Best in class USB/UART SoC converter. Do not compromise on speed and quality

CC2652P7 Autoflash mode

SLZB-07p7 features autoflash mode for СС2652P7. If you want to flash over USB – just plug-and-do!

DIY PINOUTS

SLZB-07p7 is a DIY enthusiasts friendly: it contains pinouts for CC2652P7 chip

OTHERS






NEWBY? MANUAL!

Do not know how to start? No worries, exhaustive manual is included!

REMOTE ZIGBEE UPD

You can update chip remotely! You just need to have access to the server where the adapter is connected!

ROTATABLE ANTENNA

Rotatable in 3 dimensions powerfull antenna secures best positions for the best signal

MADE IN UKRAINE

SLZB-07p7 designed, developed and tested in Ukraine. Ukrainian quality guaranteed.

SMLIGHT SLZB-07p7 SPECIFICATIONS

Main Zigbee 3.0 chip
Serial chip
Zigbee SoC output gain
Additional gain antenna
CC2652 Autoflash
Zigbee 3.0 support
Zigbee2MQTT support
ZHA support
Tiny design
Operating environment
SLZB-07p7 specification
CC2652P7
CP2102N
+20 dB
+3 dB
Yes
Yes
Yes, out of the box
Yes, out of the box
Yes, 18x54x10 mm with USB plug
+5 - +35 °C

SMLIGHT SLZB-07p7 FREQUENTY ASKED QUESTIONS (FAQ)

Does SLZB-07p7 works with Home Assistant out of the box?

Yes, it does. Just plug in SLZB-07p7 into the USB port of your server and start ZHA Home Assistant or Zigbee2MQTT.

Can I set up multiple SLZB-07p7 coodinators with one Home Assistant?

Yes, you can run multiple SLZB-07p7 with your single server. Please note, that all of them should be connected to the same server. If you want to cover different rooms or even buildings, you can use SLZB-07p7 with your server and add SLZB-06 or SLZB-06M  in other rooms or buildings. For running multiple coordinators, you just need to run a separate instance of Zigbee2MQTT or ZHA for each coordinator. More details can be found in this Article of the official manual.

Overall system architecture with multiple adapters looks like this:

Do I need to use extension cable?
In most cases, you do not need. We designed device in such a way, so it utilizes all interferences from the USB ports and can be used without extension cable!
Can I update firmware distantly, without physical access to the SLZB-07p7?

Yes, you can. Main chip used in SLZB-07p7 (CC2652P7) can be updated distantly from the other global point. That makes the device suitable for installation in rare-visited locations or installation places. You just need to have access to your server.
