✅ SLZB-MRW10 Intro
🚀 SLZB-MRW10 – Multiprotocol Smart Home Adapter (Testing Samples)
Call for Testers
We are currently distributing SLZB-MRW10 units for testing purposes. These devices have successfully completed internal testing and demonstrate stable performance across all supported networks, including Zigbee, Thread/Matter, Wi-Fi, and Z-Wave (non-certified).
After this testing phase, we plan to apply for full Z-Wave certification.
These adapters are distributed to testers strictly for evaluation and testing only. The current price reflects testing program participation, and the expected retail price (RRP) is about $75.
Overview
SLZB-MRW10 is a compact, powerful multiprotocol adapter, integrating:
-
EFR32ZG23 for non-Z-Wave certified testing (Z-Wave 800 series)
- CC2674P10 for Zigbee 3.0, Thread, and Matter over Thread (up to 400 end devices)
- ESP32 for Wi-Fi and Bluetooth LE
Designed for integration into smart home hubs, bridges, and custom automation platforms, the device provides a reliable multiprotocol foundation for next-generation development.
⚠️ Important Notice:
Z-Wave support in this device is non-certified and is included strictly for evaluation and testing purposes. These are not certified, not for commercial deployment, and are clearly labeled as non-Z-Wave certified samples.
PHOTOS
Technical Specifications – SLZB-MRW10
Radio Chips:
- Texas Instruments CC2674P10
-
- Zigbee 3.0 support (Zigbee2MQTT & ZHA compatible).
- Thread (Matter-over-Thread) support (Open Thread Border Router) .
- Ideal for Zigbee networks, works perfect also with Thread networks.
- +20 dBm TX power with built-in PA.
- Silicon Labs EFR32ZG23
-
- Z-Wave 800 support (+ Long Range). ⚠️ Important Notice: Z-Wave support in this device is non-certified and is included strictly for evaluation and testing purposes. These are clearly labeled as non-Z-Wave certified samples.
Supported Protocols:
-
- Zigbee 3.0 (Zigbee2MQTT, ZHA), at the same time with Thread.
- Thread (Matter-over-Thread), at the same time with Zigbee.
- Z-Wave (not certified, for evaluation purposes only)
- Supports simultaneous or switchable operation for multiradio environments.
- Wi-Fi and Bluetooth.
Connectivity:
- USB-C for data and power
- Ethernet connection
Firmware:
- Radio firmware support
-
- Compatible with TI Z-Stack (for CC2674P10)
- Compatible with SL Ember/EZSP stack (for EFR32MG24).
-
- Radio firmware Updating via web-interface
- SLZB-OS
- Compatible with SLZB-OS versions 2.8.7 and up.
- SLZB-OS supported functionality:
-
- VPN, 20+ languages, Scripts support, Network settings, Security, Dashboard, zHub mode, mode switcher, OTA firmware updates etc.
-
Antenna:
- Dual external antenna SMA female connectors (one for each radio SoC)
- PCB antenna for Wi-Fi and Bluetooth.
- 2x pre-packed high-gain
- – 2.4 GHz antennas for Zigbee/Thread
- – 900Mhz antenna for Z-Wave (not certified), for regions US, EU and NAZ.
Power Supply:
- PoE powered, POE 48V supported
- Powered via USB-C (5V DC)
- Low power consumption up to 1.5W (if both radio SoCs are running)
Enclosure:
- Compact, durable ABS case with ventilation
- DIN rail and wall-mount compatible (3D models)
- Easy sticking with two-sided adhesive tapes
- Easy mounting with screws with screw set (screws, screw driver, ruler) included.
LED Indicators and peripheral:
- Independent status LEDs for each radio (6 service LEDs in total: 2 LEDs for Core SoC, 2 LEDs for CC2674P10 SoC, 2 LEDs for EFR32ZG23 SoC,)
- Multibutton: supports many functions (mode switch, reset etc).
